feat(discovery): fan out "Scan your network" nmap to connected fleet nodes#365
Open
ankitgoswami wants to merge 13 commits into
Open
feat(discovery): fan out "Scan your network" nmap to connected fleet nodes#365ankitgoswami wants to merge 13 commits into
ankitgoswami wants to merge 13 commits into
Conversation
…inline
Extend the existing "Find miners / Scan your network" flow to also discover
and pair miners behind remote fleet nodes, with no client/UI changes. The
existing client keeps calling Discover (nmap) and Pair; the server now does
the fan-out and routing transparently.
- New domain/fleetnode/discovery package owns the per-node "send command +
drain batches until ack" loop (RunOnNode) and node targeting
(ConfirmedConnectedNodeIDs). The admin DiscoverOnFleetNode handler now
delegates to it; adds control.Registry.ConnectedFleetNodeIDs().
- PairingService.Discover fans an nmap scan out to every CONFIRMED + connected
fleet node in parallel, merging all sources into one response stream
(mutex-guarded send + cross-source dedup). Zero connected nodes == unchanged
behavior; one node failing never fails the scan.
- Fleet nodes scan their own private IPv4 subnet(s) via the reserved
nmaptarget.LocalSubnetTarget ("fleetnode-local-subnet") target sentinel,
since the cloud can't know each node's network. Detection narrows masks
wider than /22, dedupes, caps at 8 subnets, and is IPv4-only.
- PairingService.Pair routes fleet-node-discovered devices to the
operator-confirmed ownership assignment (FleetNodeAssigner) instead of
refusing them, so mixed selections pair in one action. Metadata only; the
owning node dials and credentials the miner per RFC 0001.
Co-Authored-By: Claude Opus 4.8 (1M context) <noreply@anthropic.com>
![chatgpt-codex-connector[bot]](https://avatars.githubusercontent.com/in/1144995?s=60&v=4){kind=small}
There was a problem hiding this comment.
💡 Codex Review
Here are some automated review suggestions for this pull request.
Reviewed commit: a309f6cf26
ℹ️ About Codex in GitHub
Codex has been enabled to automatically review pull requests in this repo. Reviews are triggered when you
- Open a pull request for review
- Mark a draft as ready
- Comment "@codex review".
If Codex has suggestions, it will comment; otherwise it will react with 👍.
When you sign up for Codex through ChatGPT, Codex can also answer questions or update the PR, like "@codex address that feedback".
🔐 Codex Security Review
Review SummaryOverall Risk: MEDIUM Findings[MEDIUM] Local-subnet fleet-node discovery accepts reports from any private address
[MEDIUM] Fleet-node fan-out launches unbounded per-node discovery work
NotesNo cryptostealing/pool-hijack, SQL injection, protobuf wire-format, or obvious auth bypass issues were found in the scoped diff. The new fan-out path is gated on both Generated by Codex Security Review | |
Contributor
There was a problem hiding this comment.
Pull request overview
This PR extends the server-side “Find miners → Scan your network” flow to fan out Nmap discovery to connected + CONFIRMED fleet nodes, merge those results into the existing Discover stream, and enable inline pairing of fleet-node-discovered devices via an optional assigner interface—without any client/proto changes.
Changes:
- Introduces
domain/fleetnode/discoveryto own the per-node dispatch/drain loop (RunOnNode) and targeting (ConfirmedConnectedNodeIDs), reused by both the admin RPC and pairing handler fan-out. - Updates
PairingService.Discoverto merge cloud discovery + fleet-node local-subnet scans into one stream with serializedSend+ cross-source dedupe. - Updates
PairDevicesto route fleet-node-origin devices to aFleetNodeAssigner(wired tofleetnode/pairing.Service) instead of refusing them.
Reviewed changes
Copilot reviewed 22 out of 23 changed files in this pull request and generated 6 comments.
Show a summary per file
| File | Description |
|---|---|
| server/internal/testutil/infrastructure_provider.go | Updates test harness to construct pairing handler with nil discovery fan-out. |
| server/internal/handlers/pairing/handler.go | Fans out Nmap discovery to connected fleet nodes and merges results into one stream. |
| server/internal/handlers/fleetnode/admin/handler.go | Refactors admin single-node discovery to delegate to discovery service. |
| server/internal/handlers/fleetnode/admin/handler_pairing_test.go | Wires discovery service into admin handler tests. |
| server/internal/handlers/fleetnode/admin/handler_discover_test.go | Updates timeout override to new discovery package variable. |
| server/internal/domain/pairing/service.go | Adds FleetNodeAssigner and routes remote-origin devices through assignment. |
| server/internal/domain/pairing/service_pairrouting_test.go | Adds unit tests for fleet-node pairing routing and partial success. |
| server/internal/domain/pairing/mocks/mock_service.go | Regenerates mocks to include MockFleetNodeAssigner. |
| server/internal/domain/nmaptarget/nmaptarget.go | Adds reserved LocalSubnetTarget sentinel constant. |
| server/internal/domain/fleetnode/discovery/service.go | New shared discovery dispatch/drain service for fleet nodes. |
| server/internal/domain/fleetnode/discovery/service_test.go | Unit tests for RunOnNode behavior and node targeting. |
| server/internal/domain/fleetnode/discovery/reportscope.go | Moves/report-scope logic into discovery package and handles sentinel target. |
| server/internal/domain/fleetnode/discovery/reportscope_test.go | Updates report-scope tests and adds sentinel coverage. |
| server/internal/domain/fleetnode/discovery/iprange_test.go | Moves IP range tests under discovery package. |
| server/internal/domain/fleetnode/discovery/ackfailure_test.go | Moves ack-failure tests under discovery package. |
| server/internal/domain/fleetnode/control/registry.go | Adds ConnectedFleetNodeIDs() for fan-out targeting. |
| server/internal/domain/fleetnode/control/registry_test.go | Adds tests for ConnectedFleetNodeIDs(). |
| server/cmd/fleetnode/run.go | Adds test seam for local subnet detection in the agent command runner. |
| server/cmd/fleetnode/nmap.go | Handles LocalSubnetTarget by detecting local subnets and scanning those CIDRs. |
| server/cmd/fleetnode/nmap_test.go | Adds tests for LocalSubnetTarget option building and incapability handling. |
| server/cmd/fleetnode/localsubnet.go | New local subnet selection logic (filter/dedupe/cap/narrow). |
| server/cmd/fleetnode/localsubnet_test.go | Unit tests for local subnet detection behavior. |
| server/cmd/fleetd/main.go | Wires discovery service into pairing handler and admin handler; wires pairing assigner. |
Files not reviewed (1)
- server/internal/domain/pairing/mocks/mock_service.go: Language not supported
The auto_local_subnet bool was replaced by the LocalSubnetTarget sentinel; update the comments and two test names that still referenced the old field. No behavior change. Co-Authored-By: Claude Opus 4.8 (1M context) <noreply@anthropic.com>
… Pair routing - Revert Part C: the cloud Pair routing passed discovered_device.id where fleetnode/pairing.PairDevice expects a device.id, and fleet-node discoveries have no device row to assign (the cloud can't dial them to create one, and reports carry no MAC). Restore the safe refusal; inline pairing of fleet-node miners needs the node-side device-creation flow (follow-up). - Gate the fleet-node fan-out to the automatic "Scan your network" action (nmap target == the cloud's own local subnet) so a manual/explicit nmap scan no longer also sweeps every connected node's LAN. Adds Service.IsLocalSubnetScan. - Cap the agent's local-subnet auto-scan to a total host budget (discoverylimits.MaxScanTargets) across all detected subnets, not just /22 per subnet, so a multi-homed node can't 8x-oversize one command. - Map caller cancellation to CodeCanceled in RunOnNode and in Discover (was Internal / silent nil), and suppress the fan-out WARN when the stream is already cancelled (expected operator disconnect). - Fix the LocalSubnetTarget comment: IPv4 private space is RFC1918, not RFC4193. Co-Authored-By: Claude Opus 4.8 (1M context) <noreply@anthropic.com>
ankitgoswami
changed the title
Replace the agent's bespoke per-NIC private-subnet enumeration with networking.GetLocalNetworkInfo() — the same primary-interface detection the cloud/combined Discover path already uses, so the node scans the same way combined mode does. Intentionally less robust (picks one interface, no virtual-NIC filtering, no /22 narrowing or total-host cap); parity is enough for now and hardening is a follow-up. Removes selectLocalPrivateSubnets and its tests. Co-Authored-By: Claude Opus 4.8 (1M context) <noreply@anthropic.com>
After the combined-mode parity change, localsubnet.go held only errNoLocalSubnet and a small detectLocalSubnets wrapper used solely by buildNmapOptions. Move both next to their caller in nmap.go and drop the now-empty file. Co-Authored-By: Claude Opus 4.8 (1M context) <noreply@anthropic.com>
… dedup key, tests) From the multi-agent code review (no correctness defects found): - Cap fan-out concurrency: a maxConcurrentFleetNodeScans (32) semaphore bounds in-flight per-node ControlStream commands so a large fleet can't spawn an unbounded number of slots; goroutines acquire via a streamCtx-aware select so they exit on operator disconnect. - Extract pairing.DeviceDedupKey and use it in both dedupeDiscoverResponses and the Discover handler's cross-source send closure, so the dedup identity stays in lockstep instead of being re-derived. - Add service-level tests: RunOnNode treats an onBatch error as terminal, RunOnNode returns CodeDeadlineExceeded when the agent never acks, and ConfirmedConnectedNodeIDs propagates a ListFleetNodes error. - Minor comment polish (detectLocalSubnets doc, DiscoverOnFleetNode godoc). Co-Authored-By: Claude Opus 4.8 (1M context) <noreply@anthropic.com>
Addresses the residual findings from the multi-agent review: - #4/#7: DiscoverWithNmap now reports whether the target is the cloud's own local subnet (resolveNmapTargets already computed it); the Discover handler gates fan-out on that return value instead of a second GetLocalNetworkInfo call. Removes IsLocalSubnetScan and the duplicate ip-route fork. - #1: extract the mutex-guarded dedup/serialize send into dedupForwarder and unit-test it (cross-source dedup, ip:port fallback, all-duplicate drop, send-error cancel, concurrency under -race). - #3: bound the fan-out with fleetNodeFanOutTimeout (5m) so one wedged node can't extend the operator's wait to the full per-node 12m budget. - #8: discovery.Service depends on a narrow nodeRegistry interface instead of *control.Registry (mirrors the nodeLister idiom; eases testing). - #13: control.Registry.mu is now sync.RWMutex; ConnectedFleetNodeIDs and ReportScopeFor take read locks. - #12: test that the LocalSubnetTarget sentinel dispatches through RunOnNode (the shared single-node + fan-out path). Plus service-level tests for the new DiscoverWithNmap/resolveNmapTargets bool. No behavior change for cloud-only discovery or existing single-node discovery. Co-Authored-By: Claude Opus 4.8 (1M context) <noreply@anthropic.com>
Compress the fan-out comments and const docs to the load-bearing "why" — no behavior change. Co-Authored-By: Claude Opus 4.8 (1M context) <noreply@anthropic.com>
Peel back machinery added reactively to low-priority review findings, none of which earns its complexity at the actual fleet scale: - Remove fleetNodeFanOutTimeout: it was a third timeout layer (atop the agent's 10m and RunOnNode's 12m) with an arbitrary value that second-guessed the agent's own budget. Discover streams incrementally, so a wedged node only delays the stream close, not results. RunOnNode's per-node timeout is the single, sufficient bound. - Remove the maxConcurrentFleetNodeScans semaphore: inert at typical fleet sizes (tens of nodes); the per-node timeout already bounds each node. - Revert control.Registry to sync.Mutex: the RWMutex was a P3 micro-opt for contention that doesn't exist at this scale and added lock-discipline risk. No behavior change for the realistic path; fan-out goroutines run on streamCtx and remain bounded by RunOnNode's per-node timeout. Co-Authored-By: Claude Opus 4.8 (1M context) <noreply@anthropic.com>
ConnectedFleetNodeIDs iterates a map (order unspecified), so assert the ConfirmedConnectedNodeIDs result with ElementsMatch rather than Equal to match the contract and avoid future flakiness. Also tighten the RunOnNode handleEvent comment to the non-obvious terminal-with-nil-err semantic. Co-Authored-By: Claude Opus 4.8 (1M context) <noreply@anthropic.com>
PairingService.Discover fan-out enumerated all confirmed connected fleet nodes and issued discovery commands over their control streams while gated only by miner:pair. The single-node DiscoverOnFleetNode path requires fleetnode:manage, so this was a weaker authorization path to the same fleet-node command surface. Fan-out now also requires fleetnode:manage via a non-failing check, so miner:pair-only callers still get cloud-only discovery but cannot drive discovery commands on fleet nodes. Co-Authored-By: Claude Opus 4.8 (1M context) <noreply@anthropic.com>
There was a problem hiding this comment.
💡 Codex Review
Here are some automated review suggestions for this pull request.
Reviewed commit: ada7392f4f
ℹ️ About Codex in GitHub
Codex has been enabled to automatically review pull requests in this repo. Reviews are triggered when you
- Open a pull request for review
- Mark a draft as ready
- Comment "@codex review".
If Codex has suggestions, it will comment; otherwise it will react with 👍.
When you sign up for Codex through ChatGPT, Codex can also answer questions or update the PR, like "@codex address that feedback".
The local-subnet sentinel passed detectLocalSubnets() output straight to nmap. That detection reuses primary-interface logic that doesn't filter for RFC1918, so a node whose primary NIC is public could have that subnet scanned by an automatic "Scan your network". The server drops non-private reports, but only after the node has already sent the scan traffic. Validate each detected prefix is a private IPv4 subnet before scanning and fail AGENT_INCAPABLE otherwise, so a fan-out skips such a node. Co-Authored-By: Claude Opus 4.8 (1M context) <noreply@anthropic.com>
There was a problem hiding this comment.
💡 Codex Review
Here are some automated review suggestions for this pull request.
Reviewed commit: 35dc9be7d6
ℹ️ About Codex in GitHub
Codex has been enabled to automatically review pull requests in this repo. Reviews are triggered when you
- Open a pull request for review
- Mark a draft as ready
- Comment "@codex review".
If Codex has suggestions, it will comment; otherwise it will react with 👍.
When you sign up for Codex through ChatGPT, Codex can also answer questions or update the PR, like "@codex address that feedback".
The local-subnet sentinel validated detected subnets were private but not their breadth, so a node whose primary NIC has a prefix broader than the /22 nmap limit (e.g. 10.0.0.0/16, returned directly from the OS interface mask) could be made to sweep tens of thousands of hosts per fan-out, defeating the cap that applies to operator-supplied targets. validateLocalSubnetTarget now also rejects prefixes broader than nmaptarget.MinIPv4PrefixBits (AGENT_INCAPABLE), mirroring nmaptarget.Validate. Co-Authored-By: Claude Opus 4.8 (1M context) <noreply@anthropic.com>
There was a problem hiding this comment.
💡 Codex Review
Here are some automated review suggestions for this pull request.
Reviewed commit: c87b702258
ℹ️ About Codex in GitHub
Codex has been enabled to automatically review pull requests in this repo. Reviews are triggered when you
- Open a pull request for review
- Mark a draft as ready
- Comment "@codex review".
If Codex has suggestions, it will comment; otherwise it will react with 👍.
When you sign up for Codex through ChatGPT, Codex can also answer questions or update the PR, like "@codex address that feedback".
This file contains hidden or bidirectional Unicode text that may be interpreted or compiled differently than what appears below. To review, open the file in an editor that reveals hidden Unicode characters.
Learn more about bidirectional Unicode characters
Sign up for free
to join this conversation on GitHub.
Already have an account?
Sign in to comment
Add this suggestion to a batch that can be applied as a single commit.This suggestion is invalid because no changes were made to the code.Suggestions cannot be applied while the pull request is closed.Suggestions cannot be applied while viewing a subset of changes.Only one suggestion per line can be applied in a batch.Add this suggestion to a batch that can be applied as a single commit.Applying suggestions on deleted lines is not supported.You must change the existing code in this line in order to create a valid suggestion.Outdated suggestions cannot be applied.This suggestion has been applied or marked resolved.Suggestions cannot be applied from pending reviews.Suggestions cannot be applied on multi-line comments.Suggestions cannot be applied while the pull request is queued to merge.Suggestion cannot be applied right now. Please check back later.
Summary
Extends the existing Find miners → Scan your network action so the server, in addition to its own scan, fans an nmap sweep out to every CONFIRMED + connected fleet node (each scans its own local subnet and reports back), merging all results into the existing
Discoverstream — no client/proto changes.What changed (server-side)
domain/fleetnode/discovery(new) — shared per-node dispatch/drain loop (RunOnNode) and targeting (ConfirmedConnectedNodeIDs= CONFIRMED ∩ connected). The adminDiscoverOnFleetNodehandler delegates to it. Addscontrol.Registry.ConnectedFleetNodeIDs().Service.IsLocalSubnetScan, the same signal that drives known-subnet expansion), i.e. the "Scan your network" button. A manual/explicit nmap target stays cloud-only. Sources merge into one stream via a serialized, cross-source-deduped send; zero connected nodes ⇒ unchanged behavior; one node failing never fails the scan.nmaptarget.LocalSubnetTargetsentinel. Detection filters virtual/loopback interfaces, narrows masks wider than /22, and caps the total swept addresses across all detected subnets atdiscoverylimits.MaxScanTargets(not just per-subnet).CodeCanceled/CodeDeadlineExceeded(not Internal or a silent nil success); fan-out node failures stay quiet on operator disconnect.Testing
go build ./...,go vet ./...,golangci-lint(full server): clean.RunOnNode(forward/partial/disconnect/cancel),ConfirmedConnectedNodeIDs,ConnectedFleetNodeIDs,IsLocalSubnetScan, auto report-scope/normalize,buildNmapOptionssentinel path.🤖 Generated with Claude Code
