Mole

A containerized microservice for molecular generation and analysis. Generates molecular variants through random mutations using RDKit. Features a REST API, web interface, and CLI tool with secure API key authentication.

---

Prerequisites

• Docker
• Docker Compose

Components

docker-compose up starts three services, not one:

Service	Role	Exposed port
backend	FastAPI service, serves /docs and /generate_molecule	8000
frontend	web interface	3000
nginx	reverse proxy over backend and frontend	80

node_modules is a named volume, not a service.

Generation is handled inline in the request: /generate_molecule calls MoleculeGenerator directly, synchronously.

The stack previously carried Postgres, Redis and a Celery worker. None were on the request path, and no module under backend/src read DATABASE_URL or the Celery settings. src/tasks.py held a second copy of the mutation code that predated the fixes in #94, and the worker never imported it, so it registered only Celery built-ins. Running that copy directly produced results RDKit could not parse in 156 of 300 runs, and silently returned the input unchanged in 29. Registering those tasks would have exposed a second, less reliable mutation path, so the stack was removed rather than wired up. See issue #101.

---

Frontend Build

The web interface is built with Vite and Tailwind CSS 4, not Create React App. CRA hardcoded Tailwind into its PostCSS pipeline and disabled project-level PostCSS config, so Tailwind 4 could not be adopted without replacing the build tooling. The migration is #110; the blocker it removed is recorded in #93.

The production image serves the static dist output from nginx. For local frontend work:

cd frontend
npm ci
npm run dev     # Vite dev server on http://localhost:3000
npm run build   # production build into dist/

The container build remains the reference: it runs npm ci followed by vite build, and serves dist. Frontend environment variables use the VITE_ prefix (VITE_BACKEND_URL, VITE_API_KEY), set as build arguments in docker-compose.yml.

Execution

To initiate the platform:

docker-compose up --build

Command Line Testing

For testing without the web interface, use the CLI. The quickest route is the prebuilt binary attached to each tagged release, which needs no Python at all:

# Linux
curl -LO https://github.com/coccinella-labs/mole/releases/download/v1.1.0/mole-linux
chmod +x mole-linux

# macOS
curl -LO https://github.com/coccinella-labs/mole/releases/download/v1.1.0/mole-macos
chmod +x mole-macos

# Windows (PowerShell)
curl.exe -LO https://github.com/coccinella-labs/mole/releases/download/v1.1.0/mole-windows.exe

Every release from v1.1.0 onwards publishes one asset per target, named mole-<target>, with .exe appended on Windows. Earlier releases used different names, and those assets keep them. See docs/cicd.md.

Assets are never renamed or moved, so a URL pinned to any tag keeps resolving to the file that tag actually published. releases/latest/download/mole-linux tracks the newest release, so it changes target whenever a new release lands. Pin the tag if you want a build that does not move under you.

To build and install it from source instead:

cd backend
python3 -m venv venv && source venv/bin/activate && pip install build && python -m build
pipx install dist/mol_platform-*-py3-none-any.whl

# Test health
mol-platform --api-key your-key --health

# Generate molecule
mol-platform --api-key your-key --generate "CC(=O)OC1=CC=CC=C1C(=O)O"

Access Points

• API Documentation: http://localhost:8000/docs
• Frontend Interface: http://localhost (through nginx) or http://localhost:3000 (frontend container directly)

The API key is required on both /health and /generate_molecule. GET /health returns 401 without it.

---

API Reference

Molecule Generation

Endpoint: POST /generate_molecule

Facilitates the creation of molecular variants through random mutations.

Request Structure

{
  "base_smiles": "CC(=O)OC1=CC=CC=C1C(=O)O",
  "num_mutations": 3,
  "mutation_types": ["substituent", "bond_order", "atom_swap"]
}

Parameters:

• base_smiles: SMILES representation (required)
• num_mutations: Mutation count (optional, default: 3, maximum: 10)
• mutation_types: Permitted mutation categories (optional)

num_mutations outside the range 0 to 10 is rejected with 400. The upper bound is a request-level limit, not a preference: each mutation searches up to 32 candidate positions, so the work a single request performs grows with the count, and the endpoint is declared async, so that work blocks the event loop for its duration. The maximum of 10 matches the ceiling the frontend already enforces on this input.

Response Structure:

{
  "original_smiles": "CC(=O)OC1=CC=CC=C1C(=O)O",
  "generated_smiles": "CC(=O)Oc1cSCN)cccc1C(=O)O",
  "molecular_image": "base64_encoded_png",
  "properties": {
    "Molecular Weight": 180.16,
    "LogP": 1.31,
    "H-Bond Donors": 1,
    "H-Bond Acceptors": 3,
    "Topological Polar Surface Area": 63.6
  },
  "requested_mutations": 3,
  "successful_mutations": 3,
  "failed_mutations": 0,
  "mutated": true
}

Mutation Counters:

requested_mutations, successful_mutations and failed_mutations count logical mutations, not candidate attempts. One requested mutation examines several candidate positions and accepts the first that both passes RDKit sanitisation and makes the structural change that mutation type promises, so successful_mutations + failed_mutations == requested_mutations always holds for a completed request.

A mutation counts as successful only if it really changed the structure. A candidate that sanitises but leaves the molecule unchanged does not count as successful, because RDKit re-perceives aromaticity during sanitisation and can silently undo a bond order edit inside an aromatic ring. Such a candidate is counted in failed_mutations instead.

mutated is true when at least one mutation changed the structure; when it is false, no mutation was applied and the returned molecule has the same structure as the input. generated_smiles is canonicalised, so its string representation may differ from original_smiles even in that case. The response still returns 200 in every completed case: the counters, not the status code, distinguish real work from a no-op.

Available Mutations:

• substituent: Introduces substituent groups
• bond_order: Adjusts bonding configurations
• atom_swap: Exchanges atomic elements

Health Verification

Endpoint: GET /health

Provides service status confirmation.

Response Structure:

{
  "status": "healthy",
  "version": "1.1.0"
}
