Thread Mesh Visualizer

A web-based tool to visualize OpenThread network topology in real-time. It communicates with an OpenThread Border Router (OTBR) to crawl the network, map connections between routers and end devices, and display link quality using a physics-based graph layout.

Features

• Iterative Crawl: Starts from the Border Router and discovers neighbors hop-by-hop using the OTBR REST API (JSON:API).
• Physics Logic: Link lengths are calculated using an Inverse Square Law based on signal strength (Link Margin or RSSI), providing a realistic spatial representation of the mesh.
• Link Filtering: Toggle visibility of weak/medium links. Hidden links stop affecting the physics simulation, allowing the graph to relax.
• CLI Import: Can parsing the output of ot-ctl meshdiag topology for instant visualization without using the REST API.
• Device Naming: Map hex addresses to friendly names via a JSON configuration file.
• Detailed Inspection: Click nodes to see RLOC16, ExtAddress, Role, IPv6 addresses, and raw diagnostic data.
• Export: Save the current topology architecture to JSON.

Prerequisites

1. OpenThread Border Router (OTBR): You need an active OTBR with the Web GUI/REST API enabled (usually on port 80 or 8081).
2. Network Access: The machine running this visualizer must be able to reach the OTBR's IP address.

Installation & Usage

You can run this as a static web page. No build process is required (Vanilla JS + CSS).

Option 1: Run Locally (Python Server)

1. Clone this repository.
2. Start a simple HTTP server in the folder:

   python3 -m http.server 8000

3. Open http://localhost:8000 in your browser.
4. Enter your OTBR URL (e.g., http://192.168.1.50:8081) and click Start Crawl.

CORS Warning: If your OTBR is on a different domain/port than your viewer, you might hit CORS restrictions.

• Workaround: Host these files on the OTBR web server directly (see Option 2).
• Or: Use a browser extension to disable CORS for testing.

Option 2: "Host It There" (Recommended)

To avoid CORS issues and CORS configuration:

1. Copy index.html, app.js, style.css, and device_names.json to the OTBR web server directory (often /usr/share/otbr-web/ or similar, depending on installation).
2. Access the visualizer via the OTBR's IP address (e.g., http://<OTBR_IP>/index.html).
3. Leave the URL field blank; it will default to the current origin.

How to Use

Method A: REST API Discovery

1. Enter the URL of your Border Router (e.g., http://10.0.0.1).
2. Click "Start Crawl".
3. The tool will:
   • Find the Border Router.
   • Find the Leader.
   • Issue Diagnostic commands to every router iteratively.
   • Draw the graph.

Method B: CLI Drop-in (Offline/Manual)

If the REST API is unavailable or failing:

1. SSH into your Border Router.
2. Run the diagnostic command:

   sudo ot-ctl meshdiag topology children ip6-addrs

3. Copy the entire output.
4. In the Visualizer, click the purple "Import CLI" button.
5. Paste the text and click Visualize!.

Controls

• Link Filter: Use the dropdown to hide weak links. This also disables their physics forces, which helps declutter dense meshes.
• Export JSON: Downloads the current vis.DataSet content for backup.

Configuration

Friendly Names

Rename device_names.json (or create it) to map Extended MAC Addresses to readable names:

{
    "b2c9a2836317bc63": "Border Router (Pi)",
    "f4ce368a0s......": "Living Room Sensor"
}

Troubleshooting

• "Failed to get data": Check the browser console (F12). If you see CORS errors, see "Installation Option 2".
• Nodes bunching up: Try filtering out weak links using the dropdown.

Credits

Developed with the assistance of Gemini 3 Pro, an AI programming assistant.
