Reberu, A Dungeon-like Level Generator for Unreal Engine!

Table of Contents

Showcase About Features Getting Started Core Concepts Configuration Extending the Plugin Credits

Showcase

About

Reberu (レベル) aka Level is a simple, extendable plugin for Unreal Engine 5 that procedurally generates dungeon-like levels by stitching together pre-made rooms based on collision detection and door locations. Users define "rooms" with a bounding box and doors; the generator handles placement, connection, and backtracking automatically. All major generation steps are overridable in C++ or Blueprint, allowing for custom rules and fully custom level layouts.

---

Features

• Room-based procedural generation — place pre-made UE5 levels as rooms and let Reberu connect them automatically
• Door system with Gameplay Tags — tag doors to control which rooms can connect to each other
• Backtracking — the generator backtracks when it gets stuck, with configurable backtrack strategies
• Configurable room selection — choose between Breadth, Depth, Random, or custom room selection methods
• Custom rules — create Blueprint or C++ UReberuRule subclasses to control whether any two rooms can connect
• Door & blocked door actors — specify per-tag actor classes to spawn at open and blocked doorways
• Editor tooling — BP_RoomBounds actor with in-editor gizmos for visually placing and editing doors
• Replication support — spawned room levels are replicated to clients via OnRep_SpawnedRoomLevels
• Blueprint-exposed hooks — K2_StartGeneration, K2_PostProcessing, and OnGenerationCompleted delegate for easy BP integration

---

Getting Started

1. Install the plugin — copy the Reberu folder into your project's Plugins/ directory and enable it in the Plugins menu.

2. Create rooms — open or create a level for each room. In the room level, place a BP_RoomBounds actor. Use the DoorEditor panel on the actor to:

   • Set the bounding box size (used for collision checks during generation)
   • Add doors with Create New Door and position them using the in-editor gizmo
   • Assign Gameplay Tags to doors to control connectivity

3. Create a UReberuRoomData data asset — for each room, create a ReberuRoomData data asset and point it to the room's level. The room bounds and door data are saved here.

4. Create a UReberuData data asset — add your room data assets to the ReberuRooms array. Assign a StartingRoom, set TargetRoomAmount, MinRoomAmount, and configure selection/backtrack methods.

5. Place a LevelGeneratorActor — add the actor to your main level. Assign your ReberuData asset and optionally enable bStartOnBeginPlay. Call StartGeneration() from Blueprint or C++ to kick off generation.

---

Core Concepts

LevelGeneratorActor

The main actor responsible for orchestrating generation. It maintains a doubly-linked list of FReberuMove nodes (one per placed room) which enables efficient backtracking. Key overridable methods:

Method	Description
ChooseSourceRoom	Picks which already-placed room to extend from
ChooseTargetRoom	Picks which room type to place next
ChooseSourceDoor	Filters available doors on the source room
ChooseTargetDoor	Filters available doors on the candidate room
PreProcessing	Runs before finalization; return false to abort
PostProcessing	Runs after generation completes
BacktrackSourceRoom	Handles reverting moves when generation is stuck

RoomBounds (BP_RoomBounds)

An editor-only actor used to define a room's bounding box and door positions. Use the DoorEditor category to create, edit, and delete doors. Door data is serialized into a UReberuRoomData data asset.

ReberuData

A primary data asset that configures an entire generation run:

• List of available rooms and the designated starting room
• Target and minimum room counts
• Room selection method (Breadth, Depth, Random, or custom)
• Backtrack method (FromTail, UntilCurrent, None, or custom)
• Max backtrack tries before generation fails
• Door actor map (keyed by Gameplay Tag) for open and blocked doorways

ReberuRoomData

A primary data asset representing a single room. Stores the level reference, bounding box transform/extent, doors (FReberuDoor array), room tags, and whether the room can connect to itself.

FReberuDoor

Represents a door on a room. Each door has:

• A unique auto-generated ID
• A world-space transform
• A box extent (for overlap checks)
• An optional Gameplay Tag
• A flag bOnlyConnectSameDoor to restrict connections to matching tags

UReberuRule

An abstract Blueprint-able UObject. Override ShouldPlaceRoom(OwningRoom, ConnectingRoom) to implement custom placement logic (e.g., prevent two boss rooms from being adjacent).

---

Configuration

UReberuData exposes the following settings:

Property	Default	Description
StartingRoom	—	The room placed first, at the world origin
ReberuRooms	—	Pool of rooms available for generation
TargetRoomAmount	10	Desired total room count
MinRoomAmount	5	Minimum rooms required to consider generation successful
MaxBacktrackTries	5	Max consecutive backtracks before giving up
RoomSelectionMethod	Breadth	How the next source room is chosen
BacktrackMethod	FromTail	How the generator backtracks on failure
DoorMap	—	Maps Gameplay Tags to door/blocked-door actor classes

---

Extending the Plugin

Subclass ALevelGeneratorActor in C++ or Blueprint to customize generation behavior. Override any of the virtual methods listed in Core Concepts. Custom ERoomSelection and ERoomBacktrack enum values (Custom1–Custom4) are provided specifically for this purpose.

To add custom placement rules without subclassing the generator, create a UReberuRule Blueprint subclass and implement ShouldPlaceRoom.

---

Credits

Took inspiration from: ProceduralDungeon, but the code and implementation is all original :).

Created by Peter Gilbert
