MCP Google Sheets Server

A Model Context Protocol (MCP) server that provides AI agents with comprehensive Google Sheets integration capabilities. This server enables AI assistants like Claude to read, create, update, and manage Google Sheets through the Google Sheets API and Google Drive API.

Security Warning

IMPORTANT: This server requires access to your Google Drive and Google Sheets data. By using this server, you are granting the connected AI assistant the ability to:

• Search for Google Sheets files you own or have access to
• Read sheet content and metadata
• Create new Google Sheets documents
• Modify existing sheet content
• Move Google Sheets to trash (not permanently deleted)

Recommendations:

• Only use this server in trusted environments
• Review the OAuth2 permissions carefully before authorizing
• Consider using a dedicated Google account for testing
• Monitor the server's access logs and activities
• Revoke access tokens when no longer needed

Features

13 MCP Tools

• Find Sheets: Search for Google Sheets in Google Drive by name or metadata
• Read Data: Retrieve data from specific ranges in Google Sheets
• Create Sheets: Generate new Google Sheets with custom configurations
• Update Data: Modify cell values and ranges with formula support (USER_ENTERED)
• Delete Sheets: Move Google Sheets to trash (recoverable)
• Append Values: Add rows to a sheet without knowing the last row
• Clear Range: Clear cell contents without deleting structure
• Batch Get: Read multiple ranges in a single API call
• Batch Update: Write to multiple ranges in a single API call
• Spreadsheet Info: Get full metadata including all tabs and named ranges
• Add/Delete/Rename Sheet Tabs: Manage individual tabs within a spreadsheet

MCP Resources & Prompts

• Resources: Sheets exposed as sheet://{sheetId} URIs for direct content inspection
• Prompts: Built-in templates for common workflows (analyze_sheet_data, create_report_template)

Security & Authentication

• OAuth2 with PKCE (S256) and CSRF state validation
• Secure token storage at ~/.config/mcp-gsheets-server/ with restricted file permissions
• Localhost-only OAuth callback server
• Minimal scopes: spreadsheets + drive.file only
• Input validation: All tool inputs validated with Zod schemas
• Automatic token refresh and persistent storage

Prerequisites

• Node.js 20 or higher
• Google Cloud Project with APIs enabled:
  • Google Sheets API v4
  • Google Drive API v3
• OAuth2 client credentials (Client ID and Client Secret)

Google Cloud Setup

1. Create or select a Google Cloud Project at console.cloud.google.com
2. Enable the required APIs:
   • Navigate to "APIs & Services" > "Library"
   • Search for and enable "Google Sheets API"
   • Search for and enable "Google Drive API"
3. Create OAuth2 credentials:
   • Go to "APIs & Services" > "Credentials"
   • Click "Create Credentials" > "OAuth 2.0 Client IDs"
   • Set application type to "Desktop application"
   • Add http://localhost:3000/oauth/callback to authorized redirect URIs
   • Download the credentials JSON or note the Client ID and Client Secret

Installation

From Source

# Clone the repository
git clone https://github.com/rcantore/mcp-gsheets-integration.git
cd mcp-gsheets-integration

# Install dependencies
npm install

# Build the project
npm run build

Configuration

Create a .env file in the project root:

GOOGLE_CLIENT_ID=your-client-id.apps.googleusercontent.com
GOOGLE_CLIENT_SECRET=your-client-secret
GOOGLE_REDIRECT_URI=http://localhost:3000/oauth/callback
PORT=3000
MCP_SERVER_NAME=gsheets-server
MCP_SERVER_VERSION=1.2.0
LOG_LEVEL=info
NODE_ENV=production

Usage with Claude Desktop

Add the server to your Claude Desktop configuration file:

macOS: ~/Library/Application Support/Claude/claude_desktop_config.json Windows: %APPDATA%\Claude\claude_desktop_config.json

{
  "mcpServers": {
    "gsheets": {
      "command": "/path/to/node",
      "args": ["/path/to/mcp-gsheets-integration/dist/index.js"],
      "env": {
        "GOOGLE_CLIENT_ID": "your-client-id.apps.googleusercontent.com",
        "GOOGLE_CLIENT_SECRET": "your-client-secret"
      }
    }
  }
}

Replace /path/to/node with your Node.js installation path (find with which node on macOS/Linux or where node on Windows).

Authentication Flow

On first use, the server will:

1. Start a local OAuth2 callback server on 127.0.0.1:3000
2. Generate an authorization URL with PKCE (S256) challenge and CSRF state parameter
3. Automatically open the URL in your default browser
4. If browser opening fails, display the URL in the server logs as fallback
5. Wait for you to authorize the application in your browser
6. Validate the CSRF state and exchange the authorization code with PKCE verification
7. Store tokens securely at ~/.config/mcp-gsheets-server/oauth-tokens.json (permissions 0600)
8. Automatically refresh tokens as needed for subsequent requests

Available Tools

find_sheets

Search for Google Sheets in Google Drive.

Parameters:

• query (optional): Search term to filter sheets by name
• maxResults (optional): Maximum number of results (1-100, default: 10)
• orderBy (optional): Sort order - name, createdTime, or modifiedTime (default: modifiedTime)

get_sheet_data

Retrieve data from a Google Sheet.

Parameters:

• sheetId (required): The Google Sheet ID
• range (optional): Cell range (e.g., A1:C10, default: A1:Z1000)

create_sheet

Create a new Google Sheet.

Parameters:

• title (required): Sheet title
• sheets (optional): Array of sheet tabs with optional name, rowCount, columnCount

update_sheet

Update data in a Google Sheet.

Parameters:

• sheetId (required): The Google Sheet ID
• range (required): Cell range to update
• values (required): 2D array of cell values
• majorDimension (optional): ROWS or COLUMNS
• valueInputOption (optional): RAW or USER_ENTERED (default: RAW). Use USER_ENTERED for formulas.

delete_sheet

Move a Google Sheet to trash.

Parameters:

• sheetId (required): The Google Sheet ID to trash

append_values

Append rows to a sheet without knowing the last row.

Parameters:

• sheetId (required): The Google Sheet ID
• range (required): Target range (e.g., Sheet1!A:A)
• values (required): 2D array of row values
• valueInputOption (optional): RAW or USER_ENTERED (default: RAW)

clear_range

Clear cell contents without deleting the sheet structure.

Parameters:

• sheetId (required): The Google Sheet ID
• range (required): Range to clear (e.g., A1:C10)

batch_get

Read multiple ranges in a single API call.

Parameters:

• sheetId (required): The Google Sheet ID
• ranges (required): Array of range strings

batch_update

Write to multiple ranges in a single API call.

Parameters:

• sheetId (required): The Google Sheet ID
• data (required): Array of { range, values } objects
• valueInputOption (optional): RAW or USER_ENTERED (default: RAW)

get_spreadsheet_info

Get full spreadsheet metadata including all tabs and named ranges.

Parameters:

• sheetId (required): The Google Sheet ID

add_sheet_tab

Add a new tab to an existing spreadsheet.

Parameters:

• sheetId (required): The Google Sheet ID
• title (required): New tab title
• rowCount (optional): Number of rows (1-10000)
• columnCount (optional): Number of columns (1-702)

delete_sheet_tab

Delete a tab from a spreadsheet.

Parameters:

• sheetId (required): The Google Sheet ID
• tabId (required): Numeric tab ID (from get_spreadsheet_info)

rename_sheet_tab

Rename an existing tab.

Parameters:

• sheetId (required): The Google Sheet ID
• tabId (required): Numeric tab ID
• newTitle (required): New tab title

Development

# Development mode with file watching
npm run watch

# Type checking
npm run typecheck

# Linting
npm run lint

# Run tests
npm test

Testing

You can test the server before integrating with Claude Desktop using the MCP Inspector:

# Install MCP Inspector globally
npm install -g @modelcontextprotocol/inspector

# Test your server
mcp-inspector node dist/index.js

Troubleshooting

Authentication Issues

• Verify your OAuth2 credentials are correct
• Check that redirect URI matches exactly: http://localhost:3000/oauth/callback
• Ensure required APIs are enabled in Google Cloud Console
• Try deleting ~/.config/mcp-gsheets-server/oauth-tokens.json to force re-authentication

Connection Issues

• Verify Node.js path is correct in Claude Desktop configuration
• Check that the built server exists at dist/index.js
• Review server logs for detailed error messages
• Ensure port 3000 is available for OAuth callback

Permission Errors

• Confirm the Google account has access to the sheets you're trying to access
• Check that the OAuth2 consent screen is properly configured
• Verify API keys have not been restricted to specific IPs or domains

Architecture

• TypeScript: Full type safety with strict compiler settings
• Google APIs: Official googleapis client library
• MCP SDK: Official Model Context Protocol implementation (Tools, Resources, Prompts)
• OAuth2 + PKCE: Secure user authentication with S256 code challenge and CSRF state
• Zod Validation: All tool inputs validated with schemas and bounds
• Error Handling: Comprehensive error handling with sanitized messages
• Logging: Structured logging with configurable levels
• esbuild: Fast bundling for production

Security Considerations

• OAuth2 tokens stored at ~/.config/mcp-gsheets-server/oauth-tokens.json with 0600 permissions
• PKCE (S256) prevents authorization code interception
• CSRF state parameter prevents cross-site request forgery
• OAuth callback server binds to 127.0.0.1 only (not accessible from network)
• Minimal OAuth scopes: spreadsheets + drive.file (no broad Drive access)
• All API requests use HTTPS
• Error messages sanitized — no internal API details leaked
• Delete operations use trash (recoverable) instead of permanent deletion
• All tool inputs validated with Zod schemas including bounds
• Server only accepts connections via MCP protocol (no HTTP endpoints)

Contributing

Contributions are welcome! Please read CONTRIBUTING.md for guidelines on how to submit pull requests, report issues, and contribute to the project.

License

This project is licensed under the MIT License - see the LICENSE file for details.

Changelog

See CHANGELOG.md for a detailed history of changes.
